Performance and Features:
● High load capacity: Balanced horizontal structure supports large-diameter and heavy rolls for heavy-duty processing.
● Easy loading: Rolls are placed horizontally, no high-altitude hoisting required, safe and convenient for roll changing.
● Smooth operation: Low center of gravity ensures stable high-speed running and consistent slitting accuracy.
● Wide material adaptability: Works well with thick paper, thick film and rigid aluminum foil that are hard to process on vertical slitters.
● Good material protection: Gentle material path prevents stretching and breaking of thin and soft materials.
● Easy maintenance: Transmission, knife and tension components are easy to access for routine upkeep.
Automatic tension control maintains constant material tension during slitting and rewinding processes, so as to improve finished product quality and production efficiency.
The automatic edge guiding system detects material position via sensors such as ultrasonic sensors or CCD sensors. Once material deviation occurs, the edge guiding controller sends commands to actuators to automatically correct the material position. In addition, the system supports tracking of printed registration marks.
Automatic slitting machines are widely applied in papermaking, printing, flexible packaging and label manufacturing industries.
Our high-speed slitting machine can reach a maximum running speed of 800m/min, and standard models can reach 200m/min and 400m/min. The actual production speed will be adjusted according to material thickness, width and slitting accuracy requirements. Generally, the stable running speed is 70%-80% of the rated speed. For example, 0.05mm thick PET film can run stably at 350m/min when the slitting width is above 50mm.
The vertical standard models feature winding diameters of 600 mm and 800 mm, with unwinding diameters of 800 mm and 1000 mm; the horizontal standard models have winding diameters of 600 mm, 800 mm, and 1200 mm, with unwinding diameters ranging from 1200 to 1600 mm. Different models support unwinding loads up to 1500 kg or even over 3000 kg. Customized solutions for specific dimensions and load requirements are available upon request.
Yes, slitting width can be customized, with the minimum slitting width down to 10mm. The number of simultaneously slit strips depends on the total material width and minimum slitting width. For example, a 1600mm wide machine can slit up to 32 strips of 50mm wide products.
The whole machine warranty period is 1 year, and core components (servo motors, PLC) have a 2-year warranty. Wearing parts mainly include knives, belts, sealing rings, bearings, etc. Knife replacement cycle is 1-3 months (depending on material hardness and usage frequency), belts 3-6 months, bearings 6-12 months. We will provide a list of common wearing parts and preferential spare parts prices.
Standard model installation and debugging take 3–5 days. For international customers, we dispatch professional engineers to perform on-site installation and debugging, along with 1–2 days of training for operators covering equipment operation, daily maintenance, and common troubleshooting.
We provide 7×24 hours technical support, and general faults can be solved through remote guidance. For home visits, we will arrange them within 48 hours.
